Description

The FaceLift® Phoenix 350 Litre is an upright van mounted window cleaning system, designed to make the most of the space in your van. The pump, flow controller and battery are secured behind a magnetic faceplate on a powder coated frame.

It is a one operator system for smaller vans, with one 100 psi pump and one digital flow controller working from a 350 litre tank.

Choose your filtration

  • Delivery Only: no purification on board, for cleaners who fill from a static purification system or a pure water filling station.
  • DI: fill from a water source and the water is purified as you use it. Advised for soft water areas.
  • RO/DI: a four stage RO/DI system that purifies the water as it enters the tank. Advised for hard water areas.

Not sure which suits your area? Types of filtration explained covers the difference, and our water softener guide covers very hard water.

Charging the battery

The lead acid leisure battery can be removed and charged from the mains with a smart charger, or charged from the van with a split charge relay or an Orion-Tr Smart battery to battery charger. Our battery charging guide explains which suits your van.

Hose reels, hose and fitting

Hose reels and hose are sold separately, so you can pick a manual reel or an electric one such as the ReelMaster™ Lite. Add them, a charger and installation from the options on this page. We fit systems at our install centres in Barry, Liverpool, Grimsby, Billericay and Northern Ireland; see Water Fed System Installation.

Need more water or a second operator? The Phoenix 500 Litre runs one or two operators in larger vans, and the Phoenix 650 Litre carries the most water of the three.

Product Specifications

  • Capacity: 350 litres
  • Layout: upright
  • Operators: 1, with one pump and one flow controller
  • Pump: 100 psi
  • Flow control: digital flow controller
  • Battery: high power lead acid leisure battery, removable
  • Frame: powder coated, with a magnetic faceplate
  • Filtration: Delivery Only, DI, or four stage RO/DI
  • Footprint: 996 mm wide, 896 mm deep, 1007 mm high (968 mm to the top of the frame), every version
  • Weights: see the specifications table
  • Hose reels and hose: not included, sold separately

Delivery & Returns

Built to order: van systems are built to order and usually delivered within 5 to 7 working days.

  • Pallet delivery: free to mainland UK. Your system arrives on a pallet, on a large vehicle with a tail lift.
  • Installation: if you add installation, your system goes straight to the install centre. If not, please don't arrange fitting until it has arrived.
  • Access: the driver needs room for a vehicle around 13m long, and flat, level, solid ground for the pallet truck. If access is tight, contact us before you order.
  • Signature: someone needs to be there to sign, so please add a phone number at checkout for the driver.
  • Failed deliveries: a redelivery is charged at £75 ex VAT.
  • Northern Ireland and the Scottish Highlands: longer delivery times and possible extra charges.
  • Returns: as an oversized item, this may not be eligible for return. Please contact our customer service team before ordering if you are unsure; the returns policy has the details.
  • More detail: our pallet delivery guide.

Delivery times are not guaranteed. Window Cleaning Warehouse cannot accept liability for items delivered to third party or unsecured addresses.

Safety

Dimension drawings for each version, to help plan the fit in your van:

CODE: FVM35D

FaceLift® Phoenix 350 Litre

  • 350 litre upright tank, 996 mm wide and 896 mm deep
  • One operator system with a 100 psi pump and digital flow controller
  • Delivery Only, DI or RO/DI filtration
  • Built by WCW, with installation available at our install centres

£1,989.75

£2,387.70

£1,989.75

Promo Available

Add To Cart To Unlock Free Shipping

Promo Available

Add To Cart To Unlock Free Shipping

Optional Extras

FaceLift® Ion-Fire Hot Water Window Cleaning System Van Systems
FaceLift® Ion-Fire Hot Water Window Cleaning System Van Systems

FaceLift® Ion-Fire Hot Water Window Cleaning System

Add hot water to your van mounted system, provide a faster clean and protect yourself during the winter.

£3,254.95

£3,905.94

FaceLift® Pole Rack Van Systems
FaceLift® Pole Rack Van Systems Powder Coated Steel

FaceLift® Pole Rack

£174.25

£209.10


Finance Options

per month (Exc. Vat)

Please note that this is just an example of possible terms. All finance agreements are facilitated by Kennet Leasing and are subject to credit checks and acceptance by both Kennet Leasing & ourselves. A full list of terms and conditions will be made available when applying for finance directly through Kennet. All finance quotes are exclusive of VAT.

Finance Breakdown

Quote based on £

Weekly Payment £

Monthly Payment £4

First Payment £

Total Amount £

Tax Relief @ 20% £

Net cost of Finance £

Note: Finance quotes exclude VAT

Finance

Finance Request Form

Description

The FaceLift® Phoenix 350 Litre is an upright van mounted window cleaning system, designed to make the most of the space in your van. The pump, flow controller and battery are secured behind a magnetic faceplate on a powder coated frame.

It is a one operator system for smaller vans, with one 100 psi pump and one digital flow controller working from a 350 litre tank.

Choose your filtration

  • Delivery Only: no purification on board, for cleaners who fill from a static purification system or a pure water filling station.
  • DI: fill from a water source and the water is purified as you use it. Advised for soft water areas.
  • RO/DI: a four stage RO/DI system that purifies the water as it enters the tank. Advised for hard water areas.

Not sure which suits your area? Types of filtration explained covers the difference, and our water softener guide covers very hard water.

Charging the battery

The lead acid leisure battery can be removed and charged from the mains with a smart charger, or charged from the van with a split charge relay or an Orion-Tr Smart battery to battery charger. Our battery charging guide explains which suits your van.

Hose reels, hose and fitting

Hose reels and hose are sold separately, so you can pick a manual reel or an electric one such as the ReelMaster™ Lite. Add them, a charger and installation from the options on this page. We fit systems at our install centres in Barry, Liverpool, Grimsby, Billericay and Northern Ireland; see Water Fed System Installation.

Need more water or a second operator? The Phoenix 500 Litre runs one or two operators in larger vans, and the Phoenix 650 Litre carries the most water of the three.

Product Specifications

  • Capacity: 350 litres
  • Layout: upright
  • Operators: 1, with one pump and one flow controller
  • Pump: 100 psi
  • Flow control: digital flow controller
  • Battery: high power lead acid leisure battery, removable
  • Frame: powder coated, with a magnetic faceplate
  • Filtration: Delivery Only, DI, or four stage RO/DI
  • Footprint: 996 mm wide, 896 mm deep, 1007 mm high (968 mm to the top of the frame), every version
  • Weights: see the specifications table
  • Hose reels and hose: not included, sold separately

Delivery & Returns

Built to order: van systems are built to order and usually delivered within 5 to 7 working days.

  • Pallet delivery: free to mainland UK. Your system arrives on a pallet, on a large vehicle with a tail lift.
  • Installation: if you add installation, your system goes straight to the install centre. If not, please don't arrange fitting until it has arrived.
  • Access: the driver needs room for a vehicle around 13m long, and flat, level, solid ground for the pallet truck. If access is tight, contact us before you order.
  • Signature: someone needs to be there to sign, so please add a phone number at checkout for the driver.
  • Failed deliveries: a redelivery is charged at £75 ex VAT.
  • Northern Ireland and the Scottish Highlands: longer delivery times and possible extra charges.
  • Returns: as an oversized item, this may not be eligible for return. Please contact our customer service team before ordering if you are unsure; the returns policy has the details.
  • More detail: our pallet delivery guide.

Delivery times are not guaranteed. Window Cleaning Warehouse cannot accept liability for items delivered to third party or unsecured addresses.

Safety

Dimension drawings for each version, to help plan the fit in your van:

WHAT'S INCLUDED?

350 litre upright tank

An upright 350 litre tank on a powder coated frame, sized for smaller vans.

Magnetic faceplate

The pump, controller and battery sit behind a magnetic faceplate, protected and easy to reach.

100 psi pump

One 100 psi pump, set up for a single operator.

Digital flow controller

A digital flow controller to set the water flow for the job.

Leisure battery

A high power lead acid battery, removable for mains charging or charged from the van.

Your choice of filtration

Delivery Only has none on board; DI purifies as you use it; RO/DI purifies as the tank fills.

KEY BENEFITS

Upright layout that makes the most of a smaller van
Upright layout that makes the most of a smaller van
One pump and flow controller, set up for one operator
One pump and flow controller, set up for one operator
Filtration to match your water, from Delivery Only to RO/DI
Filtration to match your water, from Delivery Only to RO/DI
Fitted for you at one of our five install centres
Fitted for you at one of our five install centres

WHY THIS PRODUCT?

Built by WCW

The Phoenix van system has been built by our own team since 2015.

4,000+ FaceLift systems sold

We have sold more than 4,000 FaceLift water fed systems to window cleaners.

Sized for smaller vans

A 996 mm by 896 mm footprint leaves room for reels and kit in a smaller van.

Filtration for your water

Pick Delivery Only, DI or four stage RO/DI to suit your water and how you fill up.

Fitted in around 6 hours

Book fitting at Barry, Liverpool, Grimsby, Billericay or Northern Ireland, including electric and hybrid vans.

Support after you buy

Talk to us by email, phone, WhatsApp or chat, with free engineer technical calls for customers.

Product Specifications

VERSION SKU WIDTH DEPTH HEIGHT WEIGHT, EMPTY
Delivery Only FVM35D 996 mm 896 mm 1007 mm 83 kg
DI FVM350 996 mm 896 mm 1007 mm 85 kg
RO/DI FVM350R 996 mm 896 mm 1007 mm 95 kg

RECENTLY ASKED QUESTIONS

Will the Phoenix 350 fit my van?

Every version measures 996 mm wide, 896 mm deep and 1007 mm high. Measure the load space you want to use, leaving room for your hose reel and to open the faceplate. The dimension drawings for each version are on the Safety tab, and our installation team can advise on fitting.

Can the Phoenix 350 run two operators?

No. It is a one operator system, with one 100 psi pump and one digital flow controller. For two people working from one tank, the Phoenix 500 Litre runs one or two operators from a 500 litre tank.

Which filtration option do I need?

It depends on your water and how you fill. Delivery Only suits cleaners who already have pure water from a static unit or a filling station. DI purifies the water as you use it and is advised for soft water areas. RO/DI purifies it as the tank fills and is advised for hard water areas. Types of filtration explained goes into more detail.

Can I fill it from a static RO system?

Yes. The Delivery Only version is made for that: it carries no purification on board, so you fill it with water that is already pure. Our introduction to static purification systems explains how a static set up works.

How long will the DI resin last?

It depends on how hard your water is and how much you use. Softer water and the RO/DI version, where the RO stage does most of the work, make the resin last longer. How long will my DI resin last? explains how to judge it.

How is the battery charged?

The lead acid leisure battery can be taken out and charged from the mains with a smart charger, or charged from the van as you drive with a split charge relay or a battery to battery charger. Our battery charging guide explains which suits your van.

Does it come with hose reels and hose?

No. Hose reels and hose are sold separately, so you can choose the set up that suits you. Electric reels such as the ReelMaster™ Lite, manual reels and microbore hose can all be added from the options on this page.

Can you install it for me?

Yes. We fit systems at our install centres in Barry, Liverpool, Grimsby, Billericay and Northern Ireland, usually in around 6 hours, including electric and hybrid vans. Add installation from the options on this page, or see Water Fed System Installation for the detail.

Should I choose the 350, 500 or 650 litre Phoenix?

It comes down to your van and how much water you get through in a day. The 350 is a one operator system for smaller vans, the 500 runs one or two operators in larger vans, and the Phoenix 650 Litre carries the most water of the three.
